Personalized customized PCB and fast prototyping services available.
Professional inspection machines & talents, Multi ISO certifications passed.
BOM matching success rate up to 99%, Freeing up your valuable time.
Provide professional technical support and solutions.
Customized PCBA processing mainly includes the following links:
1) PCB design and manufacturing
2) Evaluate production costs and component procurement
3) SMT patches and DIP plug-ins
4) Soldering and assembly
5) Functional testing and quality inspection
6) Packaging and delivery
PCB (Printed Circuit Board) is the basis of the entire PCBA, and its design determines the product function and performance. It provides connection and support for components to ensure the normal operation of the circuit. The entire process includes schematic design, layout and wiring, board selection, and processing and manufacturing. After the design is completed, the PCB needs to go through multiple processes such as manufacturing, etching, drilling, and pad processing.
Read More The selection of electronic components directly affects product performance and cost. We will purchase components that meet the requirements based on the BOM (Bill of Materials) provided by the customer, refer to the specific performance requirements and budget requirements of the components, and ensure the qualifications of the supplier and the quality stability of the components.
Read More This is the core link of PCBA processing. We will choose different assembly methods according to different components. - SMT (Surface Mount Technology) patch: electronic components are mounted on the surface of PCB, suitable for small components. - DIP (Dual In-line Package) plug-in: suitable for larger or specific functional components, which need to be completed by wave soldering or manual soldering.
Read More Complete the fixed connection and electrical connection of components to ensure that each component is firmly and reliably connected to the PCB. The main links include reflow soldering, wave soldering and manual soldering, and the appropriate soldering method needs to be selected according to the type of component.
Read More Testing is a key link to ensure product qualification. Verify whether the circuit performance and function are normal and troubleshoot potential problems. The process mainly includes AOI (automatic optical inspection), ICT (in-circuit testing), FCT (functional testing), etc. to ensure that product performance meets design requirements.
Read More Complete the final packaging of the product and deliver it to the customer. Regarding product packaging, we will use anti-static packaging and affix labels and logos to ensure that the product is safely delivered to the customer. It not only protects the product, but also enhances the brand image of Jeking.
Read More Shenzhen Jeking Electronic Corp.
Jeking was founded in 2016. It is a powerful supplier of PCB/diodes/integrated circuits/transistors/IoT modules, etc., and a BOM service provider with diversified professional services. We have strong production capacity, high-quality supply, and competitive prices. Able to provide customers with tailor-made solutions and customized services.
Jeking's team of experts works closely with clients to ensure that their specific needs are met. Whether it's sourcing rare components, providing technical support, or offering cost-effective alternatives, Jeking strives to exceed expectations with its competitive prices and unparalleled customer service.
By continuously innovating and adapting to the changing market demands, Jeking remains a trusted partner for electronics professionals worldwide.
JeKing,has 8 years of experience with providing wide area of specialty services works listed below.
